BOPP Thermal Lamination Film,focus on clarity and adhesion,17mic,gloss & matt
Specifications of BOPP Plastic Film:
| TYPE | THICKNESS (micron) |
| Gloss | TOTAL | BASE | EVA |
| 15 | 10 | 5 |
| 17 | 12 | 5 |
| 18 | 12 | 6 |
| 20 | 12 | 8 |
| 22 | 12 | 10 |
| 23 | 15 | 8 |
| 25 | 15 | 10 |
| 27 | 15 | 12 |
| 28 | 15 | 13 |
| 30 | 15 | 15 |
| 42 | 18 | 24 |
| WIDTH (mm) | 200 ~ 2210 |
| LENGTH (m) | 100 ~ 8000 |
| PAPER CORE | 25.4mm(1 inch) / 76mm (3 inch) |
| BONDING | ≤2 |
| CORONA TREATED | Double side |
| SURFACE TENSION | 38 Dyne/cm ≤ 42 Dyne/cm |
| LAMINATION TEMP. | 90±10°C |
| ROLLER PRESSURE | 10 ~ 20Mpa |
| LAMINATION SPEED | 20 ~ 70M |
Description of BOPP Plastic Film:
Thermal Lamination Films have extrusion-coated surface with low temperature melting resin, which enables the lamination of film to paper products by heat and pressure. Various surface finishes available add value to the printed surface. Gloss Pearl white BOPP Thermal Lamination Film provides a Gloss-finish on the surface of presswork. Compared with matt thermal lamination film, gloss film can be preserved for longer period of time.
A combination of good performance characteristics and low price point make Pearl white BOPP Thermal Lamination Film ideal for all kinds of printed & unprinted paper and paper boards, including book covers, cosmetics packaging, magazines, documents, shopping bags, Diaries etc.
Why choose NEI pearl white BOPP plastic film?
- Environmentally friendly: It is environmentally friendly, harmless to health and safe to use as it will not emit toxic gases or volatile components. Safety during lamination because no solvent-based adhesives are used.
- High Performance: Compared to other solvent laminates, our films are better in terms of transparency and adhesion. Strong powder absorption ability, prevent lamination easy to be pressed, blistering, fragmentation. Sub-photothermal composite film is suitable for point UV and hot stamping.
- Ease of operation: Once the required temperature is reached, it can be easily operated without special technology.
- High efficiency and energy saving: production cost is greatly reduced, no film waste, no adhesive solvent mixing, no ultraviolet heating lamp.
- Suitable for different types of machines: it is recommended to use this film in dry laminating machines. If the film is used in a wet laminator, minor adjustments to the machine are required.
Why chooses NEI?
- NEI has professional experience in film industry since 1995 so we have good quality control and after-sale services to support you.
- 10 years of export experience to many countries, including South America, North America, Middle East, Asia, Africa, Oceania, etc. so we have good reputation in these areas.
- Compared with other thermal lamination film, our EVA glue is 100% imported from Korea and it ensures the adhesiveness of our film.
- Customize size and thickness according to customer requests. Labels can be customized as well.
- A wide range of thermal lamination film and special films.
- Rapid production and delivery.
Special Instruction of BOPP Plastic Film:
- NEI BOPP thermal lamination film gloss film is suggested to be laminated with the roller temperature range of 85 to 110°C and roller pressure of 10 to 20 Mpa. However, the optimum conditions are depending on the selected laminator’s speed and dimensional stability.
- It is advised that the printed surface is well dried before lamination and cools sufficiently one surface before laminating to other surface.
Applications of of BOPP Plastic Film:
Packaging:
